DCX - Dialog Control Xtension

XTreebar
XTreebar is a command implemented to control the mIRC Treebar.

/xtreebar Commands
The /xtreebar command is used to control the mIRC Treebar and change various properties.
/xtreebar -c
This command changes the mIRC Treebar colors.
Syntax:
/xtreebar -c [+COLORFLAGS] [COLOUR]
Example:
/xtreebar -c +b 255
Parameters:
+COLORFLAGS Color flags.
b Background color.
e Event color.
E Event background color.
i Insert mark color.
l Line color.
s Selected text color.
S Selected background color.
t Text color.
m Message color.
M Message background color.
COLOR The color in $rgb() format.

Note. This requires /xtreebar -T to be activated.

/xtreebar -f
This command allows you to change the mIRC Treebar font.
Syntax:
/xtreebar -f [+FONTFLAGS] [CHARSET] [SIZE] [FONTNAME]
Example:
/xtreebar -f +i default 20 Verdana
Parameters:
+FONTFLAGS Font style flags.
a Font is anti-aliased.
b Font is bold.
d Default font.
i Font is italic.
s Font is strikedout.
u Font is underlined.
CHARSET Can be any of the following: ansi, baltic, chinesebig, default, easteurope, gb2312, greek, hangul, mac, oem, russian, shiftjis, symbol, turkish, vietnamese.
SIZE Font size in points.
FONTNAME Font name. Ex: Tahoma, Courier New, Arial, ...

/xtreebar -s
This command allows you to change the mIRC Treebar styles.
Syntax:
/xtreebar -s [STYLES]
Example:
/xtreebar -s tooltips scroll singleexpand
Parameters:
trackselect Enables hot-tracking.
notrackselect Disables hot-tracking.
tooltips Enables tooltips on items
notooltips Disables tooltip on items.
balloon Enables balloon styled tooltips. See note for further information.
noballoon Disables balloon styled tooltips.
infotip Enables modification of the tooltip text within the $xtreebar_callback. See note for further information.
noinfotip Disables modification of the tooltip text.
hasbuttons Enables ± buttons on the side of items containing child items for expand/collapse operations.
nohasbuttons Disables ± buttons on the side of items containing child items for expand/collapse operations.
rootlines Enables lines to be connected to the root item.
norootlines Disables lines to be connected to the root item.
singleexpand Causes the item being selected to expand and the item being unselected to collapse upon selection in the tree view.
nosingleexpand Disables singleexpand.
scroll Enables horizontal and vertical scrolling in the mIRC Treebar.
noscroll Disables horizontal and vertical scrolling in the mIRC Treebar.
showsel Selections will be shown when mIRC Treebar loses focus.
noshowsel Selections will not be shown when mIRC Treebar loses focus.
autohscroll Remove the horizontal scrollbar and auto-scroll depending on mouse position. (Vista)
noautohscroll Enables the horizontal scrollbar and auto-scroll depending on mouse position. (Vista)
doublebuffer Specifies how the background is erased or filled. (Vista)
nodoublebuffer Specifies how the background is erased or filled. (Vista)
fadebuttons Fade expand buttons in or out when the mouse moves away or into a state of hovering over the control. (Vista)
nofadebuttons Does not fade expand buttons in or out when the mouse moves away or into a state of hovering over the control. (Vista)
indent Indents the tree view for the expand buttons. (Vista)
noindent Does not indent the tree view for the expand buttons. (Vista)
richtooltip Allow rich tooltips in the tree view (custom drawn with icon and text). (Vista)
norichtooltip Disables rich tooltips in the tree view (custom drawn with icon and text). (Vista)

Note.

/xtreebar -w
This command allows you to change the mIRC Treebar images.
Syntax:
/xtreebar -w [POS] [+FLAGS] [INDEX] [FILE]
Example:
/xtreebar -w 0 + 1 icons.icl
/xtreebar -w clear
/xtreebar -w default
Parameters:
clear Clears the icon list.
default Reverts the icon list to the default icons.
POS The position to add the new icon. Use 0 to add to the end.
+FLAGS Icon flags
a Uses the icon associated with the given file (as shown in Windows Explorer).
Note: File must exist.
f Uses the icon associated with the given filetype.
Note: Filename is the extension (eg. BMP, PNG, AVI, etc).
g Convert to grayscale icon.
P If GDI+ is enabled, this will use GDI+ to extract the icon.

Note. This requires /xtreebar -T to be activated.

/xtreebar -T
This command allows you to enable or disable DCX controlled drawing of the mIRC TreeBar.
Syntax:
/xtreebar -T [0|1]
Example:
/xtreebar -T 1

Note.

$xtreebar Properties
The $xtreebar identifier is used to retrieve information about the mIRC TreeBar.
$xtreebar().icon
Returns the current icons being used by the mIRC TreeBar item.
Syntax:
$xtreebar(N).icon
Example:
$xtreebar(3).icon
Parameters:
N The index of the item.

Note. If N is 0, this property retrieves the last item in the mIRC Treebar.

$xtreebar().item
Returns the text of the mIRC TreeBar item.
Syntax:
$xtreebar(N).item
Example:
$xtreebar(3).item
Parameters:
N The index of the item.

Note.
  • If N is 0, this property retrieves the total number of items in the mIRC Treebar.
  • Returns $null if unsuccessful.
