| Panel |
The panel control is like an empty borderless dialog which is used to host other controls.
|
| Control Styles |
| These control styles are available when creating a Panel control. Remember that the general styles disabled, group, hidden, notheme, tabstop and transparent apply to all DCX controls except the embedded Dialog and Window controls. |
| alpha |
Control is alpha blended. |
| hgradient |
Draws a horizontal gradient with the colors specified. |
| vgradient |
Draws a vertical gradient with the colors specified. |
| /xdid flags |
| Control commands are input to the control with the /xdid command. |
|
/xdid -c |
| This command lets you add a child control to a panel control. |
| Syntax: |
/xdid -c [DNAME] [ID] [CID] [CONTROL] [X] [Y] [W] [H] (OPTIONS) |
| Example: |
/xdid -c dcx 4 12 richedit 10 10 400 25 multi |
| Parameters: |
| CID |
Unique control ID for the DCX Control. Must be unique for all the controls of the dialog! |
| CONTROL |
The type of DCX Control to create. Values can be:
button, calendar, colorcombo, comboex, datetime, directshow, ipaddress, listview, pbar, richedit, statusbar, toolbar, trackbar, treeview, updown, webctrl
box, check, edit, image, line, link, list, radio, scroll, text
divider, pager, panel, rebar, stacker, tab
dialog or window. |
| X |
X position of control. |
| Y |
Y position of control. |
| W |
Width of control. |
| H |
Height of control. |
| OPTIONS |
Optional styles and options available on each individual controls. |
| | | Note. If docking a mIRC @Window or mIRC Dialog, the first parameter in OPTIONS must be the @window/dialog name. |
|
/xdid -d |
| This command lets you delete a control added on the panel. |
| Syntax: |
/xdid -d [DNAME] [ID] [CID] |
| Example: |
/xdid -d dcx 4 6 |
|
/xdid -l |
| This command lets you add Cell Layout Algorithm rules to your dialog controls for automatic resizing of the child controls. |
| Syntax: |
/xdid -l [DNAME] [ID] [COMMAND] [PATH] [TAB] [+FLAGS] [CID] [WEIGHT] [W] [H] |
| Example: |
/xdid -l dcx 4 root $chr(9) +pv 0 1 0 0
/xdid -l dcx 4 root 1 2 $chr(9) +fi 7 1 200 300
/xdid -l dcx 4 space 1 $chr(9) + 5 5 5 5
|
| Parameters: |
| COMMAND |
Layout command. |
| clear |
Clears all CLA rules. |
| root |
Sets the root cell element. |
| cell |
Adds a cell element as a child of another cell element. |
| space |
Sets the space padding around a cell element. |
| update |
Updates the cell layout (must be used after adding rules or changing padding settings to refresh display). |
| PATH |
Cell Path from root element (can be root to point to root element). |
| +FLAGS |
Flags to manipulate Cell Layout Algorithm. |
| f |
Creates a fixed cell element. |
| h |
Creates a width fixed cell if used with +f or a horizontal cell pane if used with +p. |
| i |
Indicates that the supplied control ID is valid and is the child control when used with +f or +l. |
| l |
Creates a fill cell element. |
| p |
Creates a pane cell element. |
| v |
Creates a height fixed cell if used with +f or a vertical cell pane if used with +p. |
| w |
When used, it means that the supplied W and H represent the fixed cell width in the applicable direction (if the fixed cell is fixed in width, height or both). |
| CID |
ID of the control (used with fixed or fill cells - use 0 if no control is to be linked to the cell). |
| WEIGHT |
Cell child weight. (used when adding a child cell to a pane cell) |
| W |
Fixed width of control (used with fixed cell). |
| H |
Fixed height of control. (used with fixed cell) |
| | Note.- See the Cell Layout Algorithm explanation for concrete examples.
- If you use the update command in the init event of a dialog, you will have to use ".timer 1 0 xdialog -l dialog update" as a glitch with XP and themes disabled prevents windows from appearing. The timer corrects this problem.
- When using the space command, the ID WEIGHT W H are in fact the LEFT TOP RIGHT BOTTOM spacings
- Use the value 0 for the fields not used as the command expects them to be filled even though they aren't used.
|
|
/xdid -t |
| This command lets you set the text for a panel control. |
| Syntax: |
/xdid -t [DNAME] [ID] [TEXT] |
| Example: |
/xdid -t dcx 4 New Window Text |
| | | Note. The panel text (and border) is only visible when used with /xdid -x DIALOG ID +bd |
| Panel Events |
| These events are fired when activity occurs in the Panel control. |
|
dclick |
| When the left mouse button is double-clicked. |
| Syntax: |
/cb_alias DNAME dclick ID |
| Example: |
/cb_alias dcx dclick 4 |
|
help |
| Launched when you click on a control using the ? contexthelp button. |
| Syntax: |
/cb_alias DNAME help ID |
| Example: |
/cb_alias dcx help 4 |
|
lbdblclk |
| When the left mouse button is double-clicked. |
| Syntax: |
/cb_alias DNAME lbdblclk ID |
| Example: |
/cb_alias dcx lbdblclk 4 |
|
lbdown |
| When the left mouse button is pressed. |
| Syntax: |
/cb_alias DNAME lbdown ID |
| Example: |
/cb_alias dcx lbdown 4 |
|
lbup |
| When the left mouse button is released. |
| Syntax: |
/cb_alias DNAME lbup ID |
| Example: |
/cb_alias dcx lbup 4 |
|
sclick |
| When the left mouse button is clicked. |
| Syntax: |
/cb_alias DNAME sclick ID |
| Example: |
/cb_alias dcx sclick 4 |
|
